When using mechanical equipment, master some common sense. For us, it is very useful. It can help to solve problems quickly. Our paste labeling machine is the same. So the common sense of adjusting the wet glue labeling machine is for you. How much do you know?
1. Adjustment of the label box: Adjustment of the position of the grabbing hook of the labeling box: The grabbing hooks of up, down, left and right are on the same vertical plane and work hard on the label evenly, then the label can be grasped smoothly. The gap between the label paper and the bead on both sides should be between 0.8mm ~ 1mm. Too large clearance will cause the label paper to shift in the label box and oblique labeling will occur. If the clearance is too small, it will cause poor bidding. The center line of the label box, the center axis of the label station is tangent to the label paper, and the center axis of the label board is three points in a line. Adjustment of label supply roller: When there is no label, the label pressing plate can be pressed to the forefront of the label box and when the label is installed, the label near the label hook finger cannot be crushed.
2. Adjustment of the standard station: adjustment of the rubber roller and the standard plate: the standard plate and the rubber roller only contact each other without any pressure. The gap is too large, and there is too much glue on the target plate, which causes the glue to fling. The gap is too small and the contact is too tight, it will squeeze the glue away, and there is no glue on the half of the target. Adjustment of rubber scraper and rubber roller: The gap between rubber scraper and rubber roller can not appear in the whole length. If there is a gap, you can adjust the rubber scraper by adjusting the eccentric bolt. Practice has proved that the gap between the standard plate and the rubber roller is best between 0.1mm and 0.2mm. This can be achieved by adjusting the bearing seat on the lower part of the rubber roller, and adjusting the bearing on the upper part of the rubber roller if necessary.
3. Adjustment of the brushing device: adjustment of the bottle pressing head; the bottle pressing head should be 20mm lower than when there is no bottle. The overlapping gap of the pressure brush across the container is: a single pressure brush is 10 mm to 15 mm, and a combined pressure brush is 5 mm to 10 mm. The position of the cleaning brush from the sponge is 1 mm to 2 mm. The center of the marker is aligned with the label and symmetrical on both sides. The marking brush is perpendicular to the surface of the container.
4. Adjusting the star wheel for entering the bottle, the star wheel for exiting the bottle, and the screw rod for entering the bottle: adjustment of the star wheel for exiting the bottle: when the bottle pressing head is just raised, adjust the star wheel so that the bottle is located in the middle of the groove of the star wheel. Adjusting the screw rod for bottle feeding: The bottle feeding star wheel shall prevail. When the bottle is located in the middle of the groove of the bottle feeding star wheel, adjust the screw rod so that the bottle feeding side of the screw rod is close to the bottle without displacement. When adjusting the star wheel for entering and exiting the bottle and the screw rod for entering the bottle, the bottle head of the standard machine shall prevail. First adjust the bottle entry star wheel. When the bottle pressing head just overwhelms the bottle, adjust the bottle entry star wheel so that the bottle is located in the middle of the star wheel groove.
